P704 amplifier

P704 amplifier

This 4/3/2-channel amplifier is designed for flexible, powerful audio performance. It features low-level (0.25-6 V) compatible RCA inputs for versatile connectivity. With power ratings of 4 x 70 Watts RMS into 4 Ω, 4 x 110 Watts RMS into 2 Ω, and bridge configuration power of 2 x 230 Watts RMS into 4 Ω, this amplifier ensures optimum sound reproduction for your loudspeakers. The amplifier covers an extended frequency response from 10 Hz to 30 kHz, with low-pass (50 Hz – 250 Hz) and high-pass (50 Hz – 250 Hz) filters to fine-tune frequencies. It boasts a signal-to-noise ratio in excess of 90 dB and a total harmonic distortion (THD) of less than 0.05%, guaranteeing superior sonic clarity. It is protected against short circuits, low impedance, overheating and reverse polarity. The amplifier dimensions are 174 x 158 x 99 mm (6.85“ x 6.2” x 3.9″). Instructions for use are included for easy installation.

Contact us

4/3/2-CHANNEL AMPLIFIER



Technical specification

– Low-level compatible RCA inputs: 0.25-6 V
– Power (4 Ω): 4 x 70 Watts RMS
– Power (2 Ω): 4 x 110 Watts RMS
– Bridge power (4 Ω): 2 x 230 Watts RMS
– Frequency response: 10 Hz – 30 kHz
– Low pass crossover: 50 Hz – 250 Hz
– High-pass filter: 50 Hz – 250 Hz
– Signal-to-noise ratio > 90 dB
• THD < 0.05%
– Protections: short-circuit / low impedance / thermal protection / reverse polarity
– Dimensions (L x W x H): 174 × 158 × 99 mm – 6.85” × 6.2”× 3.9”



Supplied accessories :
Operating instructions



Icon

P704 usermanual

1 file(s) 620.25 KB
Download
