CR30 bass-reflex enclosure

CR30 bass-reflex enclosure

The subwoofer equipped with the Relax R12 subwoofer is a bass-reflex model with a laminar port and a 30 cm subwoofer. It offers a maximum power of 500 W and a nominal power of 250 W. Its frequency response varies from 30 Hz to 500 Hz, with a boost of 5.2 dB at 70 Hz. It has a sensitivity of 94 dB and an impedance of 2 Ω. The cabinet is made of 16 mm MDF and its dimensions are 360 mm in height, 305 mm in depth and 500 mm in length.

VIEW DISTRIBUTORS

SUBWOOFER WITH RELAX R12 SUBWOOFER



Technical details

reflex subwoofer with 30 cm laminar subwoofer port, black carpeting



Composition

MDF 16 mm
Subwoofer 300 mm Relax R12
Maximum power: 500 W / Nominal power 250 W
Frequency response 30Hz – 500 Hz
Boost 5.2 dB at 70 Hz
Sensitivity 94 dB
Impedance 2 Ω

Dimensions: H 360 mm x D 305 mm x W 500 mm.



Icon

CR30 DATA SHEET

1 file(s) 379.96 KB
Download

Looking for Blam audio products?
Find our resellers and distributors around the world.

Installers
Distributors

SUBWOOFER WITH RELAX R12 SUBWOOFER



Technical details

reflex subwoofer with 30 cm laminar subwoofer port, black carpeting



Composition

MDF 16 mm
Subwoofer 300 mm Relax R12
Maximum power: 500 W / Nominal power 250 W
Frequency response 30Hz – 500 Hz
Boost 5.2 dB at 70 Hz
Sensitivity 94 dB
Impedance 2 Ω

Dimensions: H 360 mm x D 305 mm x W 500 mm.



Icon

CR30 DATA SHEET

1 file(s) 379.96 KB
Download
GAMME

Relax
TYPE

With box
TAILLE

300mm (12")
PRODUIT

Subwoofer
