WOOFER S 6.300

Designed for powerful and precise sound reproduction, the 165 mm (6-1/2”) S 6.300 woofer offers an extended frequency response from 50 Hz to 5 kHz. With a nominal power of 125 W and a maximum power of 250 W, it delivers deep and dynamic bass. Its high-end design integrates a die-cast aluminum basket, an ultra-rigid carbon fiber cone and an NBR surround for optimal durability. Equipped with a 38 mm voice coil on a fiberglass support and an oversized magnetic motor (100 mm x 20 mm), it guarantees excellent performance and great sonic precision. Its gold-plated terminal block ensures an optimal connection for faithful and powerful reproduction. Impedance of 2 Ω for ideal compatibility with demanding audio systems.

VIEW DISTRIBUTORS

WOOFER S 6.300

Woofer 6-1/2’’ (165 mm)
Maximum power 250 W – Nominal power 125 W
Frequency response 50 Hz – 5 KHz
Impedance 2 Ω

Die-cast aluminum basket – Ultra-rigid carbon fiber cone – NBR surround – Long-life “Conex” spider – 38 mm (1.5”) voice coil on fiberglass support – Oversized 100 mm x 20 mm magnetic motor – Gold-plated terminal block



TECHNICAL DATA SHEET :

Icon

S6.300

1 file(s) 2.29 MB
Download

Looking for Blam audio products?
Find our resellers and distributors around the world.

Installers
Distributors

WOOFER S 6.300

Woofer 6-1/2’’ (165 mm)
Maximum power 250 W – Nominal power 125 W
Frequency response 50 Hz – 5 KHz
Impedance 2 Ω

Die-cast aluminum basket – Ultra-rigid carbon fiber cone – NBR surround – Long-life “Conex” spider – 38 mm (1.5”) voice coil on fiberglass support – Oversized 100 mm x 20 mm magnetic motor – Gold-plated terminal block



TECHNICAL DATA SHEET :

Icon

S6.300

1 file(s) 2.29 MB
Download
TYPE

Without box
GAMME

Signature
PRODUIT

Woofer
TAILLE

165mm (6")
